Overhead Fire Door Closers

Fire door closers close fire doors behind a person passing through the door and therefore help limit the spread of fire throughout a building. Overhead fire door closers can be mounted in three different configurations which are commonly referred to as Fig 1, 61 and 66 positions (please note that not all closers can be mounted in all configurations).

Fire door closers come either with a rated or adjustable strength to cater for different sizes and weights of doors. View our EN size guide

Filter and sort products
Page 1 (Products 1 to 20 of 21)

Union CE3F Overhead Door Closer - Power Size EN 3

  • This product qualifies for FREE shipping!
  • Fixed power size EN 3
  • 120 minute fire rating for timber fire doors
  • Adjustable closing speed and latching action
  • 10 Year Warranty

1 unit

£14.99 inc VAT

£12.49 ex VAT

5+ units

£14.51 inc VAT

£12.09 ex VAT

10+ units

£13.79 inc VAT

£11.49 ex VAT

View Product

Dorma TS68 Overhead Door Closer - Power Size EN 2/3/4

  • Selectable power size EN 2/3/4
  • 120 minute fire rating
  • Adjustable closing speed and latching action
  • 5 year warranty
6 Customer Reviews

£28.19 inc VAT

£23.49 ex VAT

View Product

Briton 121CE Overhead Door Closer - Power Size EN 3

  • Fixed power size EN 3
  • 120 minute fire rating
  • Adjustable closing speed and latching action
  • 10 Year Warranty
30 Customer Reviews

Save 8%

From: £28.55 inc VAT

£23.79 ex VAT

View Product

GEZE TS1500 Overhead Door Closer - Power Size EN 3 - 4

  • Adjustable power size EN 3-4
  • 120 minute fire rating
  • Standard closer and guide rail options available
  • 10 year warranty
1 Customer Reviews

From: £53.99 inc VAT

£44.99 ex VAT

View Product

Briton 1110 Overhead Door Closer - Power Size EN 2-4

  • Adjustable power size EN 2-4
  • 120 minute fire rating
  • Adjustable closing speed and latching action
  • 10 year warranty
5 Customer Reviews

Save 14%

From: £41.27 inc VAT

£34.39 ex VAT

View Product

GEZE TS2000V Overhead Door Closer - Power Size EN 2-5

  • Adjustable power size EN 2-5
  • 120 minute fire rating
  • Standard closer or adjustable back check available
  • 10 year warranty
5 Customer Reviews

From: £59.99 inc VAT

£49.99 ex VAT

View Product

Union CE24V Overhead Door Closer - Power Size EN 2 - 4

  • Adjustable power size EN 2-4
  • 120 minute fire rating
  • Adjustable closing speed and latching action
  • 10 year warranty

£43.19 inc VAT

£35.99 ex VAT

View Product

Dorma TS71 Overhead Door Closer - Power Size EN 3/4

  • Selectable power size EN 3/4
  • 120 minute fire rating
  • Adjustable closing speed and latching action
  • 5 year warranty

£43.19 inc VAT

£35.99 ex VAT

View Product

Dorma TS72 Overhead Door Closer - Power Size EN 2-4

  • Adjustable power size EN 2-4
  • 120 minute fire rating
  • Standard closer or adjustable back check available
  • 5 year warranty

From: £50.15 inc VAT

£41.79 ex VAT

View Product

Union RetroV Overhead Door Closer - Power Size EN 3 - 4

  • Adjustable power size EN 3-4
  • 60 minute fire rating for timber doors
  • Available in silver finish
  • 10 year warranty

£64.79 inc VAT

£53.99 ex VAT

View Product

Briton 2003V Overhead Door Closer - Power Size EN 1 - 4

  • Adjustable power size EN 1-4
  • 120 minute fire rating
  • Available in silver or gold finish
  • 10 year warranty
2 Customer Reviews

Save 15%

Now: £66.47 inc VAT

£55.39 ex VAT

View Product

Briton 1120B Overhead Door Closer - Power Size EN 2-4

  • Adjustable power size EN 2-4
  • 120 minute fire rating
  • Adjustable closing speed, latching action & back check
  • 10 year warranty

Save 8%

Now: £64.79 inc VAT

£53.99 ex VAT

View Product

Briton 2003 Overhead Door Closer - Power Size EN 3

  • Fixed power size EN 3
  • 120 minute fire rating
  • Available in silver or gold finish
  • 10 year warranty
2 Customer Reviews

From: £71.56 inc VAT

£59.63 ex VAT

View Product

GEZE TS4000 Overhead Door Closer - Power Size EN 1-6

  • Adjustable power size 1-6
  • 120 minute fire rating
  • Adjustable closing force, speed, latching action and back check
  • 10 year warranty
9 Customer Reviews

£101.99 inc VAT

£84.99 ex VAT

View Product

Briton 2004 Overhead Door Closer - Power Size EN 4

  • Fixed power size EN 4
  • 120 minute fire rating
  • Available in silver or gold finish
  • 10 year warranty

Save 16%

Now: £100.43 inc VAT

£83.69 ex VAT

View Product

Dorma TS83 Overhead Door Closer - Power Size EN 3-6

  • Adjustable power size EN 3-6
  • 120 minute fire rating
  • Available with adjustable delayed closing action
  • 5 year warranty
8 Customer Reviews

From: £136.19 inc VAT

£113.49 ex VAT

View Product

Exidor 9870 Electro-Magnetic Door Closer - Power Size EN 4

  • Door operates without resistance in normal use
  • Free-swing and hold open configuration options
  • Fixed power size EN 4
  • Adjustable closing speed and latching action
  • 10 year warranty

Save 14%

From: £130.19 inc VAT

£108.49 ex VAT

View Product

GEZE TS4000E Hold Open Door Closer - Closing Force EN 1-6

  • Adjustable power size EN 1-6
  • 120 minute fire rating
  • Adjustable closing speed and latching action
  • Manufacturer's 12 month warranty
1 Customer Reviews

£221.99 inc VAT

£184.99 ex VAT

View Product

Geofire Agrippa Acoustic Free-Swing Door Closer - Power Size EN 4

  • Door operates without resistance in normal use
  • Capable of learning the fire alarm sound
  • Fixed power size EN 4
  • Wireless installation and programming
  • Adjustable closing speed and latching action
  • 12 month manufacturer's warranty
3 Customer Reviews

Save 20%

Now: £233.99 inc VAT

£194.99 ex VAT

View Product
Back to top
Page 1 (Products 1 to 20 of 21)
CLOSEclose

Refine Your Results

Sort By

Show Prices

Delivery

(2)

Mounting Position ?

(20)
(19)
(15)

EN Power Size

(4)
(3)
(10)
(17)
(17)

Ironmongery Brand

(6)
(4)
(3)
(1)
(1)
(5)
(1)

Feature

(7)
(1)
(3)
(1)
(20)
(1)
(20)

Maximum Door Weight

(16)
(4)
(3)
(2)
(18)
(19)

Maximum Door Width

(4)
(3)
(2)
(18)
(19)
(16)

Operation

(1)
(2)

Excellent Warranties

warranty-5-plus

5+ year warranty on all our Essential Fire Safety Products

More info

Special Offers

Great deals and savings on 100's of our fire safety products

See Special Offers

New Catalogue

The latest version of our product catalogue is available now

Request Your Copy

Overhead Fire Door Closer Mounting Configurations

Overhead Fire Door Closer Mounting Configurations

Door closers can be mounted in different ways depending upon the application for which they are being used. The three most common mounting types are detailed below.

Fig 1 Mounting

Also known as regular or projecting arm, this is the standard fixing position for a universal door closer. This is where the door closer is fitted to the opening face of the door on the hinge side.

When a door closer is fitted in a "figure 1" configuration the arms of the closer will project outwards from the door at around 90°.

Please Note: Fig 1 is suitable for all fire doors.

A graphic of an overhead door closer installed in Fig. 1 configuration

Fig 61 Mounting

The second fixing position for a universal door closer is commonly referred to as "figure 61" or transom. This is where the door closer is inverted and the body of it fitted to the head of the door frame opposite the hinge side of the door. This application allows a door closer to be fitted on external doors without the closer having to be exposed to the elements.

When a door closer is fitted in a "figure 61" configuration the arms of the closer will project outwards from the door at around 90°.

Please Note: The Certifire certificate must explicitly state approval for a door closer to be compliant in this configuration.

A graphic of an overhead door closer installed in Fig. 61 configuration

Fig 66 Mounting

The third fixing position for a universal door closer is commonly referred to as "figure 66" or parallel arm. This is where the door closer is fitted to the closing face of the door opposite the hinge side of the door. The arm of the closer is then fitted to a bracket supplied with the door closer. This application allows a door closer to be fitted on external doors without the closer having to be exposed to the elements.

When a door closer is fitted in a "figure 66" configuration the arms of the closer will run parallel to the door and frame.

Please Note: The Certifire certificate must explicitly state approval for a door closer to be compliant in this configuration.

A graphic of an overhead door closer installed in Fig. 66 configuration
