10 Year Longlife Battery Radio-Interlinked Heat Alarm - Aico Ei630iRF
Product Overview
Interlink
Technical Data
The Ei630iRF heat alarm features a sealed 10 year lithium battery which is designed to last the full lifetime of the alarm. Designed for detecting fires by sensing the rise in temperature, these alarms are suitable for kitchens, lofts, or garages where dust and fumes may cause nuisance alarms. The Ei630iRF is integrated RadioLINK+ and AudioLINK+ technology, allowing for easy interlinking with other compatible alarms and capable of retrieving real-time data via an app.
- Suitable for installation in kitchens, lofts, and garages
- Battery: 10 year sealed lithium battery
- Warranty: 5 year warranty
- Easy to fit, twist-fit installation
- Large test button for simple testing and silencing
- RadioLINK+ wireless technology – capable of linking up to 12 devices
- AudioLINK+ provides real-time notifications via the app
- Suitable for installations complying to BS 5839-6: 2019 Grade F1
- Screws and fixings supplied
- CE, UKCA, and Kitemarked to BS 5446-2: 2003
- This alarm is also suitable for the updated 2022 Scottish legislation for fire alarms in homes
The table below shows all the units that can interlink with the EI630iRF.
Smoke and Heat Alarms
|
Model Number
|
Type of Unit
|
Type of Interlink
|
| Ei3014RF | Mains Powered Heat Alarm - Sealed Lithium | Radio Interlink |
| Ei3016RF | Mains Powered Optical Smoke Alarm - Sealed Lithium | Radio Interlink |
| Ei3024RF | Mains Powered Optical & Heat Alarm - Sealed Lithium | Radio Interlink |
| Ei3028RF | Mains Powered Heat & Carbon Monoxide Alarm - Sealed Lithium | Radio Interlink |
| Ei2110eRF | Mains Powered Multi Sensor Smoke & Heat Alarm - Sealed Lithium | Radio Interlink |
| Ei161eRF | Mains Powered Ionisation Smoke Alarm - Sealed Lithium | Radio Interlink |
| Ei164eRF | Mains Powered Heat Alarm - Sealed Lithium | Radio Interlink |
| Ei166eRF | Mains Powered Optical Smoke Alarm - Sealed Lithium | Radio Interlink |
| Ei168RC/141RC | Mains Powered Ionisation Alarm - 9V Alkaline | Radio Interlink |
| Ei168RC/144RC | Mains Powered Heat Alarm - 9V Alkaline | Radio Interlink |
| Ei168RC/146RC | Mains Powered Optical Smoke Alarm - 9V Alkaline | Radio Interlink |
| Ei3100RF | Battery Powered Ionisation Smoke Alarm - 9V Alkaline | Radio Interlink |
| Ei3103RF | Battery Powered Heat Alarm - 9V Alkaline | Radio Interlink |
| Ei3105RF | Battery Powered Optical Smoke Alarm - 9V Alkaline | Radio Interlink |
| Ei603RF | Battery Powered Heat Alarm - Sealed Lithium | Radio Interlink |
| Ei650RF | Battery Powered Optical Smoke Alarm - Sealed Lithium | Radio Interlink |
Carbon Monoxide Alarms
|
Model Number
|
Type of unit
|
Type of interlink
|
| Ei3018RF | Mains Powered Carbon Monoxide Alarm - Sealed Lithium | Radio Interlink |
| Ei3028RF | Mains Powered Heat & Carbon Monoxide Alarm - Sealed Lithium | Radio Interlink |
| Ei262 | Mains Powered Carbon Monoxide Alarm - Sealed Lithium | Radio Interlink |
| Ei208WRF | Battery Powered Carbon Monoxide Detector - Sealed Lithium | Radio Iinterlink |
Ancillary Products
|
Model Number
|
Type of unit
|
Type of interlink
|
| Ei170RF | Mains Powered Strobe and Vibration Pad for the Hearing Impaired - Sealed Lithium | Radio Interlink |
| Ei450 | Battery Powered Fire and CO Alarm Controller - Sealed Lithium | Radio Interlink |
| Ei411H | Battery Powered Locate, Silence & Test Control Switch - Sealed Lithium | Radio Interlink |
| Ei407 | Battery Powered Manual Call Point - Sealed Lithium | Radio Interlink |
| Ei410TRF | Battery Powered Test Remote - Sealed Lithium | Radio Interlink (Ei3100RF Series) |
| Ei428 | Mains Powered 5A Relay Module | Radio Interlink |
| Y03 | Mains Powered Multi Frequency Sounder | Hardwire Interlink (via relay) |
| SAB300C | Mains Powered Flashing Xenon Strobe (Clear) | Hardwire Interlink (via relay) |
| SAB300R | Mains Powered Flashing Xenon Strobe (Red) | Hardwire Interlink (via relay) |
Wiring Explained
Mains powered Ei Electronics smoke and heat alarms require a 230V AC power supply and up to 12 alarms can be hardwire interlinked in one system.
To obtain a mains power supply, each alarm can be connected to the nearest lighting circuit using 2 core and earth cable with a separate, dedicated interlink cable connecting alarms where applicable. However, if possible it is recommended that any alarms connected via interlink cable are all powered from a dedicated circuit from the distribution board using 3 core and earth cable for safety during maintenance, as the interlink cable will carry power from live alarms on other power circuits. Please see the diagram below:-
| Product Code | EI630IRF |
|---|---|
| Alternative Product Codes | EI603RF, EI603, Ei603, Ei603C, Ei603CRF, Ei603TYCRF, Ei603RF |
| Brand | EI Electronics |
| Battery Type | Sealed lithium |
| Dimensions (HxWxD) | 120 x 120 x 64mm |
| Humidity Range | 15 - 95% |
| Radio Linking Frequency | 868 MHz |
| Radio-Frequency Range | >100 metres |
| Sensor Type | Heat sensor |
| Sound Output | 85dB at 3 metres |
| Temperature Range | -10 to +40°C |
| Visual Indicators | Power Up: Red & Amber Standby: No coloured LEDs Testing, Activation & Memory: Red Faults: Amber RF Transmission: Blue |
| Warranty | 5 years |
| Weight | 0.20kg |
| Product Datasheets |
Pricing & Availability
| Model | Stock | Price |
|---|---|---|
| Product Code: EI630IRF |
Stock Level:
9 in stock Expected dispatch: Tomorrow
|
Price:
£86.27 inc VAT £71.89 ex VAT |
