Mains powered with a 10 year sealed lithium back-up battery, the FireAngel Pro HT-230 heat alarm can be hard-wire interlinked with up to 30 alarms within a single system. The HT-230 heat alarm is quick to detect increase in room temperature, making it ideal for areas where a smoke alarm would be prone to false activation, such as kitchens and garages.
- 230V mains powered heat alarm
- Sealed 10 year back-up battery - no need to replace for the life of the alarm
- CE marked and Kitemarked to BS EN 5446-2
- Safelincs Exclusive 5 Year Warranty
- A maximum of 30 FireAngel Pro alarms can be hard-wire interlinked
- Suitable for installations complying to BS 5839-6: 2013 Grade D, E and F
- Detects rate of increase in room temperature rather than smoke
- Ideal for use where a smoke alarm would be prone to false activation
- Easy to use test, hush and Sleep Easy™ function
- Locate function: allows you to find the alarm that activated the system
- Tamper-proof mounting plate locks the alarm head in place
- Sleek, stylish design
- Typically installed in kitchen areas and garages
- Supplied with fixings; 2 x screws and 2 x rawl plugs
In a wireless-only system the maximum number of compatible units that can interlink is 50, while a hard-wired-only system is limited to 30 units. In a mixed hard-wired and wireless alarm system these maximum quantities can be exceeded.
For each "group" of hard-wired alarms in a system, only one should be a wireless model. For example, in a 3 storey house you could hard-wire 2x ST-230 and 1x WST-230 alarms together on each floor with all of the WST-230 models wirelessly interlinked to each other. This can technically be done to a maximum of 50 groups of 30 alarms, though FireAngel has not designed, optimised, or tested these alarms for such a large system. Having so many alarms interlinked would create large communication delays between the alarms, potentially resulting in occupants not being given adequate warning of a fire. It is heavily recommended that customers desiring a large amount of alarms for a single property instead look into full Fire Alarm Systems which are designed for larger premises.
The table below shows all the units that can interlink with the FireAngel Pro alarms.
Alarms from the Same Series
||Type of unit
||Type of interlink
||Mains Powered Optical Smoke Alarm
||Mains Powered Heat Alarm
||Mains Powered Optical Smoke Alarm
||Mains Powered Heat Alarm
This is the technical data for the Mains Powered Heat Alarm with Lithium Back-up Battery - FireAngel Pro HT-230.
|Alternative Product Codes
||10 year sealed lithium
||-10 °C to +45 °C
Q. What smoke alarm should I use in a bedroom with an en suite bathroom?
A. It is usually recommended to install an optical smoke alarm in a bedroom. This is because optical smoke alarms are slightly quicker at detecting slow smouldering fires that can originate from upholstery type materials and over-heated wiring. Also, an optical smoke alarm would be less likely to sound a false alarm than an ionisation would, if steam/water droplets were present from the bathroom. Detectors should be installed as central to the room as possible; however for your application I would also consider the position of the en suite to make sure that the detector is not in the direct path of the joining door. This is just to try and avoid the chances of a false alarm. No detector is designed for use in bathroom areas.
Q. How do I safely dispose of my old smoke alarms?
A. Safelincs is signed up to Valpak's WEEE (Waste Electrical and Electronic Equipment) Distributor Take-Back Scheme (Registration ID: 7370). Private households can therefore drop off their electronic and electrical fire safety waste at their municipal recycling centre when they are purchasing new products from us. To find your nearest recycling centre, please visit www.recycle-more.co.uk.
Q. Can the mains powered smoke alarm range be connected to mains power via the lighting circuit?
A. Yes, hard-wired mains powered alarms can be wired to the unswitched live feed of the nearest frequently used lighting circuit.
Q. is there a different alarm sound for optical and heat sensors to tell you the difference in what kind of fire it is?
A. There is only one alarm sound type when a fire is detected, when interconnected all smoke and heat alarms will sound. However only the triggered alarm will have a rapidly flashing red indicator.
Q. How long do the batteries last in smoke alarms?
A. The 9V alkaline batteries last 12~18 months. Lithium batteries will usually last 5x longer than their alkaline counterparts, achieving around 5 years lifetime. Some lithium cells are also rechargeable, and when used in a mains-powered alarm may last for the entire functional lifespan of the alarm. Newer alarm models may also feature a "sealed" lithium battery. These batteries are specialist components which are designed to not be removed or need replacing by the user, and have been tested by the alarm manufacturer to ensure they last for the lifetime of the alarm.
Show all FAQs
Please Note: the actual lifetime of your batteries depends on how often the alarms are tested or activated, as sounding the alarm draws more power than when the alarms are "waiting" to detect fire. You should also read your alarm's manual to make sure you only use the recommended types and brands of batteries, as failing to follow these instructions may cause the alarm to malfunction, not alerting you in the event of a fire, and might also invalidate the warranty.
Key Product Features
Test and hush button built in to thermistor cover
Break-out tab for seamless trunk wiring
3 colour LEDs tell you its status at a glance
Includes screws and rawl plugs for installation
- 1 x FireAngel Pro HT-230 heat alarm
- 1 x Sealed 10-year lithium battery
- 2 x Screws & rawl plugs
- 1 x Instruction manual
