Polycarbonate Outdoor Defibrillator Cabinet with Code Lock, Heating System and LED Light

Polycarbonate Outdoor Defibrillator Cabinet with Code Lock, Heating and Light - Yellow

Product Overview
Compatibility
Technical Data
FAQs (2)

Product Overview

Providing a secure AED storage location for all environments, this cabinet is the first of its type on the market and is supplied with a 10 year limited guarantee as standard. Constructed from a durable polycarbonate and fitted with a removable LED light for ease of use during the darker periods of the day, this cabinet is IP66 rated giving it an exceptional ability to protect the defibrillator within against dust and water ingress whilst remaining fully recyclable. The thermostatically controlled heater built into the cabinet maintains the internal temperature to ensure the defibrillator is stored within its operating temperature range. Fitted with a marine grade keypad lock for additional security.

Suitable for all makes of defibrillator:
- Please compare cabinet and AED dimensions before purchase
Dimensions
- Internal Dimensions (HxWxD) - 400x370x160mm
- External Dimensions (HxWxD) - 465x435x240mm
Fitted with a marine grade stainless steel keypad lock for maximum security
High impact resistant polycarbonate construction
Available in yellow and green as standard
IP66 rated - providing a completely dust and water tight AED cabinet
Battery powered, motion sensor LED light for cabinet illumination. Easily detachable for use as a torch
Class II double insulated by design so can be installed in telephone boxes
Thermostatically controlled mains powered 50W heating system maintains the internal temperature
Large viewing window to enable clear sight of the defibrillator status indicator
Can be installed at coastal locations
Ideal for sports stadiums, town centres and other public access locations
UV stabilised and will not degrade in direct sunlight
Fully recyclable
10 year limited guarantee
Manufactured in the UK

Please note:

It is recommended that mains powered heated cabinets are installed by a qualified electrician. In addition to this, we would recommend that these cabinets are opened and aired out on a monthly basis to prevent condensation build up.
Not all ambulance services support or advocate the use of lockable cabinets and some do not keep or issue lock codes. Before you order, please check with your local emergency services.

Compatibility

The table below shows the defibrillators that can be stored using these cabinets. Some devices can be stored within their carry cases, but please ensure you check the dimensions of your device against the internal dimensions of the cabinet before placing your order.

Cardiac Science

Model Number	Defibrillator
STJG5SNC	Powerheart G5 Semi-Auto Defibrillator
STJG5ANC	Powerheart G5 Fully Auto Defibrillator

Defibtech

Model Number	Defibrillator
STJDTAED5	Lifeline AED Defibrillator
STJDTAUT5	Lifeline Auto Defibrillator
MMDTVIEW	Lifeline View Defibrillator
MMDTECG	Lifeline ECG Defibrillator
MMDTPRO	Lifeline Pro Defibrillator

DefiSign Life

Model Number	Defibrillator
STJDEFIFA	DefiSign Life Defibrillator Unit - Fully Automatic
STJDEFISA	DefiSign Life Defibrillator Unit - Semi-Automatic

HeartSine

Model Number	Defibrillator
AHHS350P	Samaritan PAD 350P Defibrillator
AHHS360P	Samaritan PAD 360P Defibrillator
AHHS500P	Samaritan PAD 500P Defibrillator

iPAD

Model Number	Defibrillator
STJIPADFA	iPAD SP1 Defibrillator Unit - Fully Automatic
STJIPADSA	iPAD SP1 Defibrillator Unit - Semi-Automatic

Mediana

Model Number	Defibrillator
RMMEDA15	HeartOn A15 Defibrillator
RMMEDA16FA	Mediana HeartOn A16 Defibrillator Unit - Fully Automatic
RMMEDA16SA	Mediana HeartOn A16 Defibrillator Unit - Semi-Automatic

Philips

Model Number	Defibrillator
STJHHDWC	HeartStart HS1 Defibrillator
STJHSFRX	HeartStart FRx Defibrillator
STJHSFR3	HeartStart FR3 Defibrillator

Physio-Control

Model Number	Defibrillator
PCLPCRFAAED	Lifepak CR Plus Fully Auto Defibrillator
PCLPCRSAAED	Lifepak CR Plus Semi-Auto Defibrillator
PCLP1000SA	Lifepak 1000 Defibrillator
PCLP1000ECG	Lifepak 1000 ECG Defibrillator
PCCR2SAWFH	Lifepak CR2 Semi-Auto Defibrillator with WiFi
PCCR2FAWFH	Lifepak CR2 Fully-Auto Defibrillator with WiFi
PCCR2FA3GB	Lifepak CR2 Fully-Auto Defibrillator with WiFi & 3G
PCCR2SA3GB	Lifepak CR2 Semi-Auto Defibrillator with WiFi & 3G
PCLPCR2ESAED	Lifepak CR2 Essential Semi-Auto Defibrillator
PCLPCR2EFAED	Lifepak CR2 Essential Fully-Auto Defibrillator

Primedic

Model Number	Defibrillator
PMHSPAD	HeartSave PAD Defibrillator
PMHSAED	HeartSave AED Defibrillator
PMHSAEDM	HeartSave AED-M Defibrillator

Schiller

Model Number	Defibrillator
AZFREL	FRED Easy Life Fully Auto Defibrillator
AZFRE	FRED Easy Semi-Auto Defibrillator
AZFREP	FRED Easyport Pocket Defibrillator

Zoll

Model Number	Defibrillator
STJAEDPLUS	Zoll AED Plus Semi-Auto Defibrillator
STJAEDPLFA	Zoll AED Plus Fully Auto Defibrillator

Technical Data

Product Code	Yellow: DSPCLHLED Green: DSPCLHLEDG
Construction	Durable Polycarbonate
Dimensions (HxWxD)	External: 465x435x240mm Internal: 400x370x160mm
Heater Wattage	50 Watt
Weight	DSPCLHLED: 10kg DSPCLHLEDG: 10kg
Product Datasheets	Polycarbonate 4000 Datasheet Polycarbonate 4000 Installation Manual

FAQs (2)

Q. Are locked AED cabinets allowed?

For added security against misuse you may wish to have a lockable cabinet, for indoor cabinets, it is important that the key or key holder is easily accessible so that the defib can be removed quickly in the event of an emergency.

For outdoor cabinets, code locks give additional security against casual vandalism and theft, but may signal the device is valuable and other crime prevention measures, like door-open alarms and tracking devices, should be considered instead of or as well as a code lock. This is in line with guidance from the Resuscitation Council UK. If your defib is to used as a public access device, you will need to make sure that your local ambulance service is willing to store the access code so that in an emergency the cabinet can be unlocked.

Q. Can defibrillators be kept outside or in low temperatures?

Defibrillators can be kept outside but must be kept in specially designed outdoor heated cabinets to protect them against the elements. Defibrillators have an operating temperature, usually between 0 °C to +50 °C, if the temperature falls below 0 °C the defib may not work as expected. Prolonged exposure to low temperatures is likely to significantly shorten the service life of the battery and affect the performance of the pads. Most defibs have an IP Rating of IP55 meaning that prolonged exposure to wind (dust) and rain may also damage the defib meaning that it may not work when required in an emergency.

Key Product Features

Suitable for all makes and models of defibrillator

Marine grade stainless steel keypad lock

Thermostatically controlled mains powered heating

High impact resistant polycarbonate construction

Pricing & Availability

Model	Stock	Price
Yellow Product Code: DSPCLHLED	Stock Level: Available for pre-order Expected dispatch: 2nd May	Price: £551.03 inc VAT £459.19 ex VAT
Green Product Code: DSPCLHLEDG	Stock Level: Available for pre-order Expected dispatch: 2nd May	Price: £551.03 inc VAT £459.19 ex VAT
