XFP Networkable Repeater Panel - 32 Zones
Product Overview
Technical Data
Up to 8 XFP networkable 32 zone repeaters can be connected to a single main addressable fire alarm panel. The connection is achieved using network communication cards. The XFP networkable 32 zone repeater panel is supplied with a communication card as standard, and a separate 32 zone card is needed for the main addressable fire alarm panel.
- Acts as an additional central control unit for an addressable system
- Up to 8 repeaters can be connected to one XFP main 32 zone panel
- Supplied with a network communication card as standard
- Offers all the functions and controls of a main XFP panel
- CE marked
- Includes a fault relay
- Suitable for surface or semi-flush mounting
- Requires its own dedicated mains power and battery back-up supply
- Maximum cable length per repeater network: 500m
- Please note: The panel requires a 3.2Ah 24V back-up battery. These are sold separately.
Technical Data
This is the technical data for the XFP Networkable Repeater Panel - 32 Zones.
| Product Code | FLXFPR32 |
|---|---|
| Weight | 4.50kg |
| Dimensions | Back box: 410x250x80mm Lid: 439x274x7mm |
| Mains Supply | 230V a.c. ± 10% 50/60Hz |
| Internal Power Supply | 27V d.c. nominal |
| Total Output Current | 3A @ 230V a.c. |
| Max. no. of repeaters | 8 |
| Max. cable length per repeater network | 500m |
Product Datasheets
The following datasheets are available for this product.
Pricing & Availability
| Model | Stock | Price |
|---|---|---|
| Product Code: FLXFPR32 |
Stock Level:
Available to order Expected dispatch: 25th Feb
|
Price:
£413.99 inc VAT £344.99 ex VAT |
