Call Point Cover 'Stopper' with Sounder STI 6532 (for flush mounted call points)

Discontinued Product

This product has been discontinued and is no longer available to buy.

View Alternative Product
Product Overview

This flush mounted call point cover with integrated sounder is constructed from tough and durable polycarbonate. The cover is designed to protect flush mounted call points from accidental or malicious misuse and prevent false alarms. The integrated sounder not only indicates which call point has been activated but also provides an added deterrent to would-be vandals. Ideal for retrofitting in schools, colleges, nursing homes or any other location with a history of false alarms.

  • Constructed from tough clear polycarbonate
  • Protects equipment from accidental operation, vandalism, product misuse, dust and weather
  • Lifetime guarantee against breakage in normal use
  • Easy to install, can retrofit over existing call points
  • Flush mounted for a sleek look
  • Sounder emits a piercing 96 dB alarm (at 1meter)
  • Dimensions (HxWxD): 197x105x57mm
  • Clear cover with red information panel
Additional Information
Fitting Instructions
  • Position the Stopper frame centrally over the device to be protected, and mark the position for the four fixing screws.
  • Drill the holes, assemble the frame and hinge mechanism and fit the Stopper with the wall fixings and screws provided.
  • If a surface spacer is included, ensure that the plastic lip of the spacer is pointing upwards. This will provide a base for the hinge (see diagram below).
  • Ensure the deactivation pin is removed from the alarm unit on those fitted with integral sounder. The pin should be retained, in the event any maintenance work is carried out.
  • The surface spacer provides cable entry facilities for conduit, cable and trunking. A 30mm depth spacer is supplied as standard. An optional 50mm spacer is available.
  • Where an optional weather gasket is positioned between the Stopper frame and spacer. Ensure the adhesive side of the weather gasket is fixed to the spacer and not the Stopper frame.
  • To replace the 9V PP3 battery in the alarm unit, replace the deactivation pin, remove the two screws on the underside of the alarm unit and replace battery. Re-assemble ensuring to remove the deactivation pin. The pin should be retained.
Technical Data
Product Code ST6532
Brand STI Europe
Case Material

Polycarbonate

Colour

Clear with red info panel

Dimensions (HxWxD)

197x105x57mm

Sound Output

96 dB at 1 metre

Weight 0.40kg
