LED Recessed Emergency Downlight with Heat Alarm - Lumi‑Plugin

Discontinued Product

This product has been discontinued and is no longer available to buy.

View Alternative Products
Product Overview

The Lumi-Plugin switchable emergency downlight with heat alarm combines a dimmable LED light with advanced heat detection in one convenient product. Both the light and the heat alarm are supported by battery backup to ensure your continued safety in the event of a loss of mains power. A choice of warm white or cool white light output suits the style and mood of any room, while the wireless interlink enables all occupants to be alerted in the event of a fire emergency.

  • Suitable for maintained and non-maintained operation
  • Switchable emergency lighting function – maintained operation only
  • Emergency battery backup for both light and alarm
  • Wirelessly interlink with other Lumi-Plugin heat and smoke alarms
  • Suitable for BS 5839-6: 2019 Grade D2 installations
  • Fire rated to 30 / 60 / 90 minutes
  • Water and dust ingress protection – IP65 rated
  • Heat alarm: 3 year warranty – can be replaced independently of the LED light
  • Energy efficient mains powered LED downlight:-
    • Warm white option: 2700K colour temperature
    • Cool white option: 4000K colour temperature
    • 700 lumens from only 9.5W
    • Both light options are dimmable
    • 5 years / 50,000 hours warranty
  • Built to the highest construction standards
  • Stylish and sleek design in a white finish

Please note: Lumi-Plugin downlights are built with a single colour of LED light per unit. Light colour is not interchangeable by the user. Please be certain of your required LED light colour when ordering.

Technical Data

Technical Data

This is the technical data for the LED Recessed Emergency Downlight with Heat Alarm - Lumi‑Plugin.

Product Code
Warm White (2700K) LP120WH/WARM/HA/EM
Cool White (4000K) LP120WH/COOL/HA/EM
Weight
Warm White (2700K) 1.55kg
Cool White (4000K) 1.55kg
Input Voltage 220V - 240V AC
Lamp Type 9.5W LED
Light Output 700 lumens
Beam Angle 60°
Fire Rating 30 / 60 / 90 minutes
Dimensions (HxDia) 70x120mm
Colour Temperature 2700K (warm white) or 4000K (cool white)
IP Rating IP65
Operating Temperature +4°C to +38°C
Operating Humidity Up to 95% RH non-condensing
Back-Up Battery Heat Alarm: Replaceable CR2 battery
LED Light: Rechargeable battery pack
Sound Output Heat Alarm: 85dB (minimum) at 3m
