GEZE TS5000 Overhead Door Closer with Guide Rail EN 2-6
The GEZE TS5000 is a guide rail door closer. The TS5000 offers a fully variable closing action making it ideal to meet DDA recommendations. The guide rail closing system allows for easier opening of the door whilst making the closer less vulnerable to vandals. There are two versions available, designed for either pull (hinge) side or push (opposite hinge) side installations and both have an adjustable power size of EN 2-6.
- Suitable for single action doors in internal environments
- Concealed guide rail design to deter vandalism and damage to the closer
- Universal fixing allows installation on both push and pull sides, supporting
- Suitable for door leaves up to 1400 mm wide, with adjustable closing force () and clear optical size indicator
- Fully adjustable operation including closing speed, latching action, and backcheck for smooth, controlled performance
- Certifire approved (CF145), BWF certified, and fire-rated up to FD120
- Manufactured in Germany with a 10-year warranty
- DDA-compliant design meets BS 8300 requirements for accessible door operation
- Full classification: 4 | 8 | 2–6 | 1 | 1 | 4
Customer Reviews (2)
Reviews by Real Customers
All of our product reviews are written by real customers that have purchased this product from us and are published without modification.
Reviewed by
J F
Published on
24th May 2022
Reviewed by
Anonymous
Published on
17th February 2014
Good product
Technical Data
| Product Code | GZTS5000L |
|---|---|
| Brand | Geze |
| Back Check | Adjustable |
| Closing Speed | Adjustable |
| Compliance | Certifire - CF145 |
| Door Type | Single Door |
| EN Classification | 4 | 8 | 2-6 | 1 | 1 | 4 |
| Finish | Silver |
| Fire Rating | 120 Minutes |
| Fixing Options | Wooden Door Fixings (Included) |
| Installation Position | Fig 1 |
| Fig 61 | |
| Top Of Door | |
| Latching Action | Adjustable |
| Material | Metal |
| Power Size | EN 2 - 6 |
| Recyclable | Partially Recyclable |
| Warranty | 10 Years |
| Dimensions (Unit) |
|
| Weight | 500g |
| Datasheets |
