GEZE TS5000 ISM Double Door Overhead Door Closer - Power Size EN 2-6
The GEZE TS5000 ISM is an overhead door closer and guide rail set suitable for rebated double-leaf doors. There are two versions available, designed for either pull side (hinge) side or push side (opposite hinge) side installations and both have an adjustable power size of EN 2-6. The correct closing sequence of double-leaf doors is achieved by a closing sequence control function. This function allows for the second closing or "master" door leaf to wait (hold in place) until the first closing or "slave" door leaf is closed. Suitable for a maximum 1400mm leaf width, the GEZE TS5000 ISM has an adjustable closing speed, back check, and latching action.
- 10 year warranty
- CE marked
- Certifire approved – CF145 certificate
- Made in Germany
- 120 minute fire rating
- Made up of 2 overhead door closers and a connecting guide rail
- Two versions available:
- Pull side (hinge side) installation
- Push side (opposite hinge side) installation
- Designed for rebated double leaf doors
- Maximum leaf width: 1400mm
- Integrated mechanical closing sequence control
- Adjustable and
- Silver finish as standard
Customer Reviews (0)
Reviews by Real Customers
To make sure that all our reviews are real and accurate, we only allow customers that have purchased this product from us to write reviews.
No Reviews Available
No reviews have been written for this product yet.
If you have purchased this product from us and would like to write a review about it please complete the product review from. Please Note: to ensure the accuracy of our reviews you will need to provide a valid order number to leave a review.
Review this product nowTechnical Data
GEZE TS5000 Body Only
| Product Code | GZCTS5000 |
|---|---|
| Back Check | Adjustable |
| Closing Speed | Adjustable |
| Compliance | BS EN 1154: 1997 |
| BWF Certified | |
| Certifire - CF145 | |
| Door Type | Single Door |
| EN Classification | 4 | 8 | 2-6 | 1 | 1 | 4 |
| Finish | Silver |
| Fire Rating | 120 Minutes |
| Installation Position | Fig 1 |
| Fig 61 | |
| Top Of Door | |
| Latching Action | Adjustable |
| Maximum Door Width | 1400mm |
| Maximum Door Weight | 120kg |
| Warranty | 10 Years |
| Dimensions (Unit) |
|
| Weight | 500g |
GEZE TS5000ISM Guide Rail
| Product Code | GZCTS5000ISM |
|---|---|
| Brand | Geze |
| Material | Metal |
| Recyclable | Not Recyclable |
| Finish | Silver |
| Dimensions (Unit) |
|
