Kidde Surface Mounting Relay Pattress - SMK23RU
Designed for the Kidde Firex range of mains powered smoke and heat alarms, the SMK23RU surface mounting relay pattress can be used where cable access is via trunking or conduit. With a suitable relay control it can trigger auxillary devices such as door closers and warning lights / strobes.
- 230V mains powered
- Relay output for triggering external devices when alarms activate
- Designed for installations with surface mounted cabling
- Entry holes and trunking entry ports designed for the Firex alarms
- Simple to fit – suitable for retrofit
- Warranty: 6 Years
- CE marked
Customer Reviews (2)
Reviews by Real Customers
All of our product reviews are written by real customers that have purchased this product from us and are published without modification.
Reviewer
Anonymous
Published on
25th November 2017
Reviewer
Anonymous
ok but could be better Relay works fine and no need for a seperate pattress as there is room for the wiring but terminal cover screws very small and fiddly and the screw receptacle very flimsy. One rounded off straight away then broke. Also the gap for the wires to pass through is tightish even with 1.5sqmm wire.
Published on
6th June 2016
Technical Data
| Product Code | KESMK23RU |
|---|---|
| Brand | Kidde |
| Manufacturer's Part Number | SMK23RU |
| Approvals & Markings | CE Marked |
| Colour | White |
| Compatible Products | Kidde Firex Alarms |
| Equipment Type | Base |
| Operating Temperature | 0°C To +40°C |
| Power Type | Mains Powered (230V) |
| Relative Humidity | Up To 93% |
| Warranty | 6 Years |
| Dimensions (Unit) |
|
| Weight | 120g |
A useful accessory to enable alarm to be linked to household burglar alarm (or other system). The connections are somewhat fiddly and the instructions a little sparse.
