GEZE TS1500 Overhead Door Closer - Closing Force EN 3 - 4
- Suitable for use on Single Action doors
- Suitable for internal applications
- 10 year warranty
- Made in Germany
- Available in 2 versions:
- TS1500 - Standard overhead door closer
- TS1500/GR - Overhead door closer with guide rail
- BWF Certified
- Fire rating: FD120
- Direct fitting template - allows for a quick and easy installation and eliminates the need for a backing plate
- Maximum leaf width 1100mm (EN 3-4)
- Universal fixing for push and pull side mounting
- Adjustable closing force by shoe position
- Adjustable closing speed
- Adjustable latching action
- CE Marked to EN 1154, EN 1158
- CE and Certifire Approved CF144
This is the technical data for the GEZE TS1500 Overhead Door Closer - Closing Force EN 3 - 4.
| Dimensions (HxWxD) | Closer Body: 50x177x39mm |
|---|---|
| EN Size | 3-4 |
| Adjustable Closing Speed | Yes |
| Adjustable Back Check | No |
| Adjustable Latching Action | Yes |
Product Options
| Model | Product Code | Product Weight |
|---|---|---|
| TS1500 - Standard Door Closer | GZTS1500 | 1.65 kg |
| TS1500/GR - Door Closer with Guide Rail | GZTS1500/GR | 0.5 kg |
Technical Data Sheets
The following technical data sheets are available for this product:
Q.Can you please explain the closing force rating 1-6 for door closers?
A.The closing force rating 1-6 relates to the maximum width and weights of door that the door closer is suitable for and if you click on the link below and then click on the EN size guide this gives the table with the closing force categories and the relevant maximum door widths and weights. http://www.safelincs.co.uk/Door-Closers/
Pricing & Availability
| Model | Stock Levels | Prices |
|---|---|---|
|
TS1500 - Standard Door Closer Product Code: GZTS1500 |
In Stock
|
£38.99 inc VAT (£32.49 ex VAT) |
|
TS1500/GR - Door Closer with Guide Rail Product Code: GZTS1500/GR |
Low Stock
|
£61.99 inc VAT (£51.66 ex VAT) |
